| NO. |
Item |
Unit |
Specification |
Condition |
| 1 |
Rated Voltage |
VDC |
5 |
|
|
| 2 |
Operating Volt |
VDC |
4 - 7 |
|
| 3 |
Mean Current |
mA |
Max.30 |
Applying rated voltage direct current |
|
| 5 |
Sound Output |
dBA |
85/10cm |
Distance at 10cm(A-weight free air), Applying rated voltage direct current |
|
| 6 |
Rated Frequency |
Hz |
2400 |
|
|
| 7 |
Operating Temp |
℃ |
-20-+70 |
|
|
| 8 |
Storage Temp |
℃ |
-30-+80 |
|
|
| 9 |
Dimension |
mm |
L12.8×W12.8×H10.0 |
See attached drawing. |
|
| 10 |
Weight |
gram |
2.8 |
|
|
| 11 |
Material |
|
PPS(Gray) |
|
|
| 12 |
Terminal |
|
Pin type |
See attached drawing |
|
| 13 |
Storage life |
month |
3 |
3 months preservation at room temp(25±3℃),Humidity40% |
|
| 14 |
Environmental |
|
RoHS |
Internal PCB solder joints contain exempt high temperature lead Tin |
| Protection Regulation |
|
