MSW-A1240H08TR
12 * 8 mm
inclusum
X: 110°±15 Y:70°±10
40±1.0 KHz
150 min
Dual use
Specification
| Item | Unitas | Specification |
| Centrum Frequency | Hz | 40±1.0k |
| Munus | Transmittentes et accepto (Dual usu) | |
| Construction | Aquae probationem | |
| Terminal | PIN | |
| Echo sensibilitas | mV | 150 min |
| Labe tempus | ms | 1.1 max |
| directivitas X-axis | deg | 110±15 |
| directivitas Y-axis | deg | 70±10 |
| capacitas electrica | PF | 1800±15% |
| Interea ad defectum | 50000h * | |
| Maximum initus licita voltage | Vp-p | 140(40K HZ ) pulsus latitudo 0.5ms, intervallum 20ms |
| operating Tem.Range | ℃ | -20 to +70 |
| Repono Temerature | ℃ | -30 ad +80 |
| habitationi Material | aluminium |
Aspectus Tractus
