Ultrasonic Sensor

Leading High Frequency Ultrasonic Sensor Manufacturer

MANORSHI Electronics Co., Ltd. supplies high-frequency ultrasonic sensors, which are also called SML type transducers. The sealed matching layer type transducers are designed especially for factory automation and level measurements, which include two major matching layer materials, Silicone Rubber and Glass Filled Resin. We usually use Glass Filled Resin. In addition, our customers also use it for deviation corrector, anemometers, liquid level meters, etc.

The transducers consist of a metal housing with the integral metal diaphragm. They operate at resonance on the first harmonic overtone. The backs of these transducers are completely sealed with resin, protecting them from exposure to the environment.
Although it is constructed to be watertight, it is not recommended for use underwater.

The high-frequency ultrasonic sensor is a transceiver. Our main frequency is 100kHz, 125kHz, 200kHz, 300kHz, 400kHz and etc, the measuring distances are from a few centimeters up to around 20 meters.

If you have any questions or suggestions, please share them with Manorshi.

High Frequency Ultrasonic Sensor Products

Image Product Name Model Dimension Construction Directivity Using Method
100KHz High Frequency Ultrasonic Sensor Transducer 100KHz High Frequency Ultrasonic Sensor Transducer MSW-A40100H17TR--W 40*17mm Enclosed 12°±2° (-3dB) Dual use
125KHz High Frequency Ultrasonic Liquid Level Sensor 125KHz High Frequency Ultrasonic Liquid Level Sensor MSW-P25125H25TR--W 25*25MM Enclosed 14°±2° (-6dB) Dual use
High Frequency 165kHz Ultrasonic Sensor Water Level High Frequency 165kHz Ultrasonic Sensor Water Level MSW-P20165H16TR--W 20 * 16MM Enclosed 14°±2°(-6dB) Dual use
175kHz high frequency Ultrasonic Transducers with MSW-A 175kHz high frequency Ultrasonic Transducers with MSW-A MSW-A27175H13TR--W 27*3.5MM Enclosed 7°±2°(-6dB) Dual use
200kHz IP67 18mm Waterproof Ultrasonic Sensor for natural Gas Flow 200kHz IP67 18mm Waterproof Ultrasonic Sensor for natural Gas Flow MSW-G18200H09TR-W50 18*9MM Enclosed 9°±2° (-6dB) Dual use
200kHz High Frequency Waterproof Ultrasonic Sensor 200kHz High Frequency Waterproof Ultrasonic Sensor MSW-A18200H10TR 18.5*10.5MM Enclosed 7°±2° (-6dB) Dual use
200khz High Frequency Ultrasonic Range Finder Sensor 200khz High Frequency Ultrasonic Range Finder Sensor MSW-A12200H19TR--W 20*12MM Enclosed 30°±2° (-6dB) Dual use
10mm 300khz High Frequency Ultrasonic Sensor Transducer 10mm 300khz High Frequency Ultrasonic Sensor Transducer MSW-A10300H07TR 10*7MM Enclosed 7°±2° (-6dB) Dual use
400khz high frequency ultrasonic printer sensor 400khz high frequency ultrasonic printer sensor MSW-A11400H11TR 11 * 11MM Enclosed 7°±2° (-3dB) Dual use
1MHz Waterproof Ultrasonic Fuel Level Sensor Water Flow Sensor 1MHz Waterproof Ultrasonic Fuel Level Sensor Water Flow Sensor MSW-A211MH10TR 21 * 10MM Enclosed 5-10° Dual use
