10mm 300khz High Frequency Ultrasonic Sensor Transducer
Model:
MSW-P10300H08TR
Dimension:
10*8MM
Construction:
Enclosed
Directivity:
11°±2° (-6dB)
S/N Ratio:
300.0±15.0KHz
Using Method:
Dual use
Inquire
Add to Basket
Product Description
Product Description
Part Number
MSW-P10300H08TR
Construction
High-frequency
Using method
Dual use
Center frequency
300.0±15.0KHz
Bandwidth
24.0KHz
Echo Sensitivity
1.5V min.
Min. Parallel Resistance
150Ω±30％
Capacitance
1200Pf±20%
Max.Input Voltage(Pulse)
60Vp-p
Directivity (-3dB)
11°±2° (-6dB)
Distance of Detection
0.1~0.3m
Protection Class
IP65
Material
Plastic
Operating temperature
-20°C~+70°C
Storage Temperature
-35°C~+80°C
High Frequency Transducer
