5v SMT Piezo Buzzer Small Size 70db for Glucometer

  • SM11PT02A
  • 11.0* 11.0 * 1.7mm
  • 5Vp-p
  • 4100±500Hz
  • ≥70dB@10cm
  • ≤3mA
  • 1~25Vp-p

Specification

TypeUnitSM11PS02A
Operating Voltagevp-pMax 25Vp-p
Rated Current(max) mA3mA (Max)
Sound output at 10cmdBMin 70dB(Typ.)at 5Vp-p,4 khz
Rate FrequencyHz4000
Capacitance pF13000±30%
Operating temperature-30~+70
Storage Temperature -40~+85
Weight g0.2
Housing material LCP


Appearance Drawing

11PT02A
