3.6V 85dB 2730Hz SMD Square Magnetic Buzzer

  • SM08ET04A
  • 8.5 * 8.5 * 4.0mm
  • 3.6Vp-p
  • 2730±500Hz
  • ≥85dB@10cm
  • ≤100mA
  • 2.5~4.5Vp-p


Type SM08ET04A
Min.Sound Pressure level at 4KHz/3V/10cm85
Rated Voltage (Vp-p )3.6V
Operating Voltage (Vp-p) 2.5~4.5V
Rate Frequency2730Hz
Max.Rated Current100mA
Coil Resistance16±3Ω
Operating Temperature-20~+70
Storage Temperature-30~+80
Housing materialLCP
Weight 0.8g

Appearance Drawing
