Image Product Name Model Dimension Rated Voltage Resonant Frequency SPL Current Operating Voltage Details
//jlrorwxhjiilll5q.ldycdn.com/cloud/lnBqoKliRlmSkpkrmrnq/HLB1fEvyRSzqK1RjSZPxq6A4tVXa4-60-60.jpg 9.0 * 3.2mm 5V 85dB ac SMD buzzer with side sound hole SM09ET03B 9.0 * 3.2 mm 5 Vp-p 2731±500Hz ≥85dB@10cm ≤80mA 3 - 8 Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/lpBqoKliRlmSjpkmnmnp/SMT-9650-nurse-call-system-small-magnetic-60-60.jpg SMT 9650 nurse call system small magnetic buzzer with sealing epoxy SMD SM09ES05A 9.6 * 9.6* 5.5mm 5 VDC 2700±100Hz Min.85dB MAX. 30 mA 4-7 VDC View detail »
//jlrorwxhjiilll5q.ldycdn.com/cloud/ljBqoKliRlmSjpnpqrnp/SM09PT02A-5V-85db-9-9-1-8mm-60-60.png 3V 65db 9 * 9 * 1.8mm SMD small piezo Buzzer SM09PT02A 9.0 * 9.0* 1.8mm 3Vp-p 4000±500Hz ≥65dB@10cm ≤5mA 1 ~25Vp-p View detail »
//jlrorwxhjiilll5q.ldycdn.com/cloud/nnBpoKliRliSqirllplmj/SM12PT03B-60-60.jpg 5V 83db 12 * 3mm SMD small piezo Buzzer SM12PT03B 12.0 * 12.0 * 3.0mm 5Vp-p 4100±500Hz ≥83dB@10cm ≤5mA 1 ~25Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/liBqoKliRloSlqnpnknp/small-size-SMD-electro-magnetic-Buzzer-with-3V-for-Intelligent-Watch-60-60.jpg Small Size SMD Electro Magnetic Buzzer with 3V for Intelligent Watch SM04ET02A 4.0 * 4.0 * 2.0mm 3Vp-p 4000±500Hz ≥70dB@10cm ≤90mA 2~4Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/ljBqoKliRloSlqlprrnq/3V-5V-75dB-MiniI-SMD-5020-magnetic-buzzer-60-60.jpg 3V 5V 75dB Mini SMD 5020 Magnetic Buzzer SM05ET02A 5.0* 5.0 * 2.0mm 3Vp-p 4000±500Hz ≥75dB@10cm ≤110mA 2~4Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/lpBqoKliRloSlqjpnknq/3V-5V-75dB-5030-cell-phone-Mini-SMD-Buzzer-SMT-magnetic-buzzer-60-60.jpg 3V 5V 75dB 5030 Cell Phone Mini SMD Buzzer SMT Magnetic Buzzer SM05ET03A 5.0 * 5.0 * 3.0mm 5Vp-p 4000±500Hz ≥75dB@10cm ≤110mA 4~7Vp-p View detail »
//jlrorwxhjiilll5q.ldycdn.com/cloud/loBqoKliRloSlqqpmjnp/3-6v-7525-thin-electro-magnetic-smd-buzzer-60-60.jpg 3.6v 7525 Thin Electro Magnetic Smd Buzzer SM07ET03A 7.5 * 7.5 * 2.5mm 3.6Vp-p 2731±500Hz ≥80dB@10cm ≤100mA 2.5~4.5Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/npBpoKliRliSqiiljllqi/8530-60-60.jpg 3V 3.6V 5V 9V 85db Ultrathin SMD Magnetic Sounder SMT Buzzer SM08ET03A 8.5 * 8.5 * 3.0mm 3.6Vp-p 2731±500Hz ≥86dB@10cm ≤100mA 2.5~4.5Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/nnBpoKliRliSqijlrrlmi/8540-60-60.jpg 3.6V 85dB 2730Hz SMD Square Magnetic Buzzer SM08ET04A 8.5 * 8.5 * 4.0mm 3.6Vp-p 2730±500Hz ≥85dB@10cm ≤100mA 2.5~4.5Vp-p View detail »
//jlrorwxhjiilll5q.ldycdn.com/cloud/lnBqoKliRloSlqnqkrnq/3V-SMD-magnetic-Buzzer-9025-used-for-medical-Instrument-60-60.jpg 3V SMD Magnetic Buzzer 9025 Used for Medical Instrument SM09ET03A 9.0 * 2.5mm 3Vo-p 2700±500Hz ≥85dB@10cm ≤90mA 2.5~4.5Vo-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/lqBqoKliRloSlqlqmqnp/3-6v-80db-2700hz-small-smd-magnetic-buzzer-60-60.jpg 3.6v 83db 2730hz Small Smd Magnetic Buzzer SM09ET03A 9.0 * 2.5mm 3.6Vp-p 2730±500Hz ≥83dB@10cm ≤110mA 2.5-4.5Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/lqBqoKliRloSlqnqlinq/1-5V-3-6V-5V-80dB-2731Hz-External-Magnetic-Micro-Buzzer-60-60.jpg 1.5V 3.6V 5V 85dB 2730Hz External Magnetic Micro Buzzer SM09ET04A 9.0 * 4.0mm 3.6Vp-p 2730±500Hz ≥85dB@10cm ≤100mA 2.5-4.5Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/niBpoKliRliSqiilolloj/SM09ES05A-60-60.jpg 3V 85dB SMT 9650 Small Magnetic Buzzer for Nurse Call System SM09ES05A 9.6 * 9.6 * 5.5mm 3Vp-p 2700±300Hz ≥85dB@10cm ≤30mA 2.5~4.5Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/liBqoKliRloSlqnqlnnp/3v-external-drive-5v-ac-smd-piezo-buzzer-60-60.jpg 3v External Drive 5v Ac Smd Piezo Buzzer SM10PT03A 10.0 * 3.0mm 3Vp-p 15000±30%Hz ≥75dB@10cm ≤3mA 1~25Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/lrBqoKliRloSlqnqiqnp/3-6V-90dB-SMD-Transducer-SMT-Magnetic-Passive-Buzzer-60-60.jpg 3.6V 90dB SMD Transducer SMT Magnetic Passive Buzzer SM10ET03A 10.0 * 10.0 * 3.2mm 3.6Vp-p 2830±500Hz ≥ 85dB@10cm ≤90mA 2-5Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/nrBpoKliRliSqiiljrlki/SM11PT02A-60-60.jpg 5v SMT Piezo Buzzer Small Size 70db for Glucometer SM11PT02A 11.0* 11.0 * 1.7mm 5Vp-p 4100±500Hz ≥70dB@10cm ≤3mA 1~25Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/liBqoKliRloSlqoqqinp/5V-80dB-4000Hz-Miniature-smd-buzzer-lateral-sound-SMT-Buzzer-60-60.jpg 5V 75dB 4000Hz Miniature Smd Buzzer Lateral Sound SMT Buzzer SM12PT03A 12.0 * 12.0 *3.0mm 3Vp-p 4000±500Hz ≥75dB@10cm ≤5mA 1~20Vp-p View detail »
//ikrorwxhjiilll5q.ldycdn.com/cloud/liBqoKliRloSlqoqnknp/4khz-85dB-small-SMD-buzzer-60-60.jpg 4khz 85dB Small SMD Buzzer SM13PT02A 13.0 *13.0 * 2.5mm 5Vp-p 4000±500Hz ≥85dB@10cm ≤3mA 1~25Vp-p View detail »
//rjrorwxhjiilll5q.ldycdn.com/cloud/lnBqoKliRloSlqkqqpnp/small-5v-smd-magnetic-SMD-active-buzzer-for-radio-frequency-identification-60-60.jpg Small 5v Smd Magnetic SMD Active Buzzer for Radio Frequency Identification SM13ES10A 12.8 * 12.8 * 10.0mm 5VDC 2400±500Hz ≥85dB@10cm ≤30mA 4~7VDC View detail »

SMD buzzer refers to the buzzer of the plastic shell, appearance, and size of smaller, roll tape packaging, the pin can be flat to the PCB, patch type package is a relativeto plug-in type is another form of packaging of the buzzer.  The  product  has  the  advantages  of  small  size,  lightweight,  sound clear.It's widely used in small electronic equipment, such as MP4,bluetooth,reverse sensor, medical instruments, toys camerasand auido DVD,water dispenser and so on.we can also do custom active piezo buzzer,passive piezo buzzer or magnetic buzzer for our customer.
