MANORSHI is a radar level sensor manufacturer and supplier specializing in non-contact radar measurement instruments for industrial liquid tanks, cement silos, bulk material storage and process vessels. Our product range includes 80GHz radar level sensors with 4-20mA output for continuous industrial level monitoring.
MANORSHI radar level sensors are available for liquid level measurement and solid material height monitoring. Selected models provide measuring ranges up to 120 meters, specified measurement accuracy of 2mm, 12–24VDC power supply and standard 4-20mA analog output.
Our radar level measurement product range includes general-purpose liquid and solid level sensors, high-temperature radar level sensors, corrosive liquid radar sensors and cement silo radar level sensors. Different models are designed for different process conditions and installation requirements.
MANORSHI supplies radar level measurement equipment for industrial automation companies, tank manufacturers, chemical processing equipment suppliers, water treatment equipment manufacturers and industrial instrumentation distributors.
Customers can select suitable radar level sensors according to measuring range, accuracy, operating frequency, output signal, process connection, temperature and measured medium. Product datasheets, mechanical drawings and samples can be requested for engineering evaluation.
Request a Radar Level Sensor QuoteRequest Product Datasheets
MANORSHI offers six radar level sensor models for different industrial measurement applications. The range includes silo level monitoring, high-temperature liquid measurement, corrosive liquid tank monitoring and general liquid and solid material level measurement.
| Model | Main Application | Radar Frequency | Measuring Range | Accuracy | Output |
|---|---|---|---|---|---|
| MNSLL-H101 | Silo and bulk material level measurement | 80GHz | 0.05–120m | 2mm | 4–20mA |
| MNSLL-H102 | High-temperature level measurement | Confirm datasheet | 0.05–120m | 2mm | 4–20mA |
| MNSLL-H103 | Corrosive liquid tank measurement | 80GHz | Confirm datasheet | 2mm | 4–20mA |
| MNSLL-H105 | Cement silo and bulk material measurement | 76–81GHz listed; confirm version | 0.05–120m | Confirm datasheet | 4–20mA |
| MNSLL-H106 | Liquid and solid material level measurement | Confirm datasheet | 0.05–120m | 2mm | 4–20mA |
| MNSLL-H108 | General liquid and solid level measurement | 80GHz | 0.05–120m | 2mm | 4–20mA |
The product specifications above summarize the currently published model information. Most listed models use a 12–24VDC power supply and support flange or threaded installation. Please confirm the latest model-specific datasheet for radar frequency, measuring range, accuracy, process temperature and installation requirements.
MNSLL-H105 has inconsistent accuracy information in its current product materials. Confirm the approved accuracy specification before using this parameter for equipment design or procurement comparison.
Request Radar Level Sensor Specifications
A radar level sensor is a non-contact industrial measurement instrument that uses microwave signals to determine the distance between the sensor and the surface of a liquid or solid material. It calculates the material level based on the reflected radar signal and the configured reference distance.
Radar level measurement is commonly used in industrial storage tanks, process vessels, cement silos, chemical tanks and bulk material storage systems. Because the sensor measures without direct contact with the medium, it can be used in applications where conventional contact measurement methods are difficult to install or maintain.
Depending on the model and antenna design, radar level sensors can measure liquids, powders, granules and other solid materials. Important selection parameters include radar frequency, measuring range, accuracy, antenna design, output signal and process connection.
Non-contact measurement without direct contact with the measured material.
Continuous level monitoring for industrial tanks and silos.
Suitable models for liquid and solid material measurement.
High-frequency radar options for industrial level monitoring.
4–20mA analog output for industrial control systems.
12–24VDC power supply on selected MANORSHI models.
Flange and threaded mounting options on selected models.
Application-specific configurations for different process conditions.
A radar level sensor transmits microwave signals toward the surface of a liquid or solid material. Part of the transmitted energy is reflected back to the antenna. The instrument processes the received signal to calculate the distance to the material surface and determine the level relative to a configured reference point.
The radar antenna transmits electromagnetic microwave signals toward the measured material surface. The signal frequency and antenna design depend on the selected radar level sensor.
When the microwave signal reaches the material surface, part of the energy is reflected toward the sensor. The reflected signal depends on the material's dielectric properties, surface condition, geometry and installation environment.
The sensor processes the transmitted and received radar signals to determine the distance between the antenna reference point and the material surface. The calculation method depends on the radar measurement technology used in the selected instrument.
The material level is calculated using the configured tank or silo reference height and the measured distance. For a tank with a known reference height, the instrument can convert the measured distance into a continuous level value.
The sensor sends the calculated level information to an external monitoring or control system. MANORSHI radar level sensor models provide 4–20mA analog output for integration with compatible PLCs, indicators and industrial control equipment.
Radar level sensors are available in different operating frequency bands. The selected frequency, antenna design and measurement technology influence beam characteristics, installation requirements and suitability for different tank applications.
80GHz radar level sensors use millimeter-wave signals for non-contact level measurement. The relatively short wavelength can support compact antenna designs and narrow beam angles when the antenna is properly engineered.
Selected MANORSHI models, including MNSLL-H101, MNSLL-H103 and MNSLL-H108, are listed as 80GHz radar level sensors. They are designed for industrial liquid and solid material level measurement applications.
26GHz radar level sensors are another established option for industrial level measurement. Their suitability depends on the antenna design, measuring range, process conditions and required accuracy.
The MNS-LSR 26GHz model is an older MANORSHI product listing. It is currently marked as unavailable and should not be treated as a standard in-stock product. Contact MANORSHI to confirm whether an alternative model can meet the same application requirements.
| Comparison | 80GHz Radar | 26GHz Radar |
|---|---|---|
| Operating Frequency | 80GHz | 26GHz |
| Wavelength | Shorter wavelength | Longer wavelength |
| Antenna Design | Compact antenna designs are possible | Depends on antenna structure |
| Beam Characteristics | Can support narrow beam designs | Depends on antenna design |
| Selection Factors | Antenna size, beam angle and process conditions | Range, antenna design and installation conditions |
Radar frequency alone does not determine measurement accuracy or performance. Antenna design, signal processing, material properties and installation conditions must also be considered when selecting a radar level sensor.
Radar and ultrasonic level sensors both provide non-contact level measurement, but they use different physical principles. Radar sensors use electromagnetic microwave signals, while ultrasonic sensors use acoustic sound waves.
| Comparison | Radar Level Sensor | Ultrasonic Level Sensor |
|---|---|---|
| Measurement Principle | Microwave electromagnetic signals | Ultrasonic acoustic waves |
| Signal Propagation | Electromagnetic waves | Sound waves through air |
| Temperature Influence | Generally less affected by air temperature variations | Sound velocity changes with air temperature |
| Gas and Vapor Conditions | Often suitable for demanding vapor environments, subject to process conditions | Gas composition and vapor may affect acoustic propagation |
| Typical Applications | Industrial tanks, silos and process vessels | Water tanks and general level monitoring |
| Selection Factors | Frequency, antenna, dielectric properties and process conditions | Sound propagation, temperature and target surface |
Radar level measurement is often preferred for challenging industrial environments involving vapor, temperature variations or dust. Ultrasonic level measurement can be suitable for less demanding applications where acoustic propagation conditions are stable. The final choice should be based on the actual medium and installation environment.
Radar level sensors can be designed for different measured media. Liquid and solid materials have different surface characteristics, dielectric properties and reflection behavior. The correct sensor configuration should be selected according to the medium and storage vessel.
Radar liquid level sensors are used to measure the height of liquids in storage tanks, process vessels and industrial containers. The sensor is generally installed above the liquid surface and measures the reflected radar signal without direct contact with the liquid.
Typical applications include industrial liquid storage, water tanks, chemical process vessels and liquid monitoring systems. For corrosive media, the antenna and process connection materials must be compatible with the chemical properties of the liquid.
Radar solid level sensors measure the height of bulk materials stored in silos, hoppers and industrial storage vessels. Typical materials include cement powder, grains, granules and other bulk solids.
The material surface may be uneven or moving during filling and discharge. Engineers should consider dust concentration, material dielectric properties, filling points and the internal geometry of the silo when selecting a radar level sensor.
Continuous radar level monitoring provides ongoing information about the material level. The measurement output can be connected to PLCs, industrial controllers and monitoring systems to support inventory management, process control and material handling.
Industrial radar level sensors are used in applications requiring continuous non-contact measurement of liquids and bulk materials. The suitable model depends on the measured medium, tank structure, process temperature and required measurement range.
Cement silos and bulk material storage systems require continuous level monitoring to support inventory management and material handling. Radar level sensors can measure material height without direct contact with cement powder or other stored solids.
The MANORSHI MNSLL-H101 and MNSLL-H105 are specifically listed for silo and bulk material level measurement applications.
Chemical storage systems require suitable level monitoring equipment for different liquid media and operating conditions. Non-contact radar measurement can help reduce direct sensor exposure to the stored liquid.
The MNSLL-H103 is listed for corrosive liquid tank level measurement. Before installation, confirm the compatibility of the antenna, housing and process connection materials with the specific chemical medium.
Industrial tanks and process vessels may operate at elevated temperatures. The selected radar level sensor must have a process temperature rating suitable for the actual medium and installation environment.
The MNSLL-H102 is listed as a high-temperature radar level sensor. Confirm the maximum permissible process temperature and any antenna or mounting restrictions before selecting the product.
Industrial liquid storage tanks use radar level sensors for continuous level measurement and inventory monitoring. The MNSLL-H106 and MNSLL-H108 are listed for liquid level measurement and solid material height monitoring.
Process vessels use continuous level measurement to support production monitoring and automated control. A 4–20mA radar level sensor can transmit level information to compatible PLCs and industrial control systems.
Radar level measurement can be considered for water storage tanks, wastewater vessels and industrial liquid monitoring. The selected sensor should be evaluated according to tank dimensions, surface conditions, vapor and environmental protection requirements.
Radar level sensor specifications determine the measurement capability and compatibility of the instrument with the industrial process. Engineers and purchasing teams should evaluate the following parameters before selecting a model.
Radar operating frequency indicates the microwave frequency used by the level measurement instrument. MANORSHI offers selected 80GHz radar level sensor models for industrial applications.
The frequency band, antenna structure and signal processing influence the measurement characteristics. Confirm the actual frequency of each model before finalizing the equipment specification.
Measuring range indicates the distance over which the sensor can measure the material surface under specified conditions. Selected MANORSHI models are listed with a measuring range of 0.05–120 meters.
The required range should account for tank height, installation reference point, antenna position and the sensor's minimum measuring distance or blind zone.
Measurement accuracy indicates the difference between the measured value and the actual material level under specified operating conditions. Selected MANORSHI models are published with 2mm measurement accuracy.
Always check the accuracy specification for the selected model and the conditions under which it is measured. Do not assume that every model in the product range has an identical accuracy rating.
The 4–20mA analog output is widely used in industrial instrumentation and process control. It allows radar level measurements to be transmitted to compatible PLCs, controllers, indicators and monitoring systems.
Confirm whether the selected model uses a two-wire or four-wire connection and check the electrical requirements of the receiving control system.
The power supply voltage must match the selected sensor and control system. Selected MANORSHI radar level sensor models are specified for 12–24VDC operation.
Process temperature refers to the temperature of the measured medium, while ambient temperature refers to the surrounding environment. These parameters may have different limits and should be checked separately.
Selected MANORSHI product specifications list operating temperatures from -40°C to +130°C. Confirm the permissible process temperature and mounting conditions for the exact model.
Process connections determine how the radar level sensor is installed on the tank or vessel. Selected models support flange or threaded mounting.
For corrosive media, the antenna, housing, seals and process connection materials must be compatible with the measured liquid. Obtain the material specification before approving the instrument for chemical applications.
Protection ratings such as IP67 and IP68 describe resistance to dust and water ingress under specified test conditions. Do not assume an IP rating without the manufacturer's supporting documentation.
For outdoor and industrial installations, also evaluate humidity, vibration, condensation, dust concentration and exposure to chemicals.
Selecting a suitable radar level sensor requires matching the measurement range, medium, accuracy, electrical output and installation conditions to the actual industrial application. The following factors help engineers and purchasing teams evaluate different models.
Determine whether the sensor will measure water, chemicals, oils, cement powder, grains, granules or other bulk materials. Liquid and solid materials have different reflection characteristics and may require different sensor configurations.
Measure the tank or silo height and determine the maximum distance from the antenna to the material surface. Include the sensor installation height, reference point and minimum measuring distance in the calculation.
Determine the required accuracy based on the application. Inventory monitoring, process control and high-precision measurement may have different requirements. Check the model-specific accuracy under the intended process conditions.
Choose the radar frequency according to the required antenna design, beam characteristics, tank geometry and measured medium. For applications requiring narrow beam coverage, request the actual beam angle and antenna specifications.
Evaluate the maximum and minimum process temperatures and pressures. The sensor housing, antenna, seals and process connection must be suitable for the actual operating conditions.
For corrosive liquid applications, identify the chemical composition, concentration and operating temperature. Confirm the compatibility of all exposed materials, including the antenna and process connection.
Determine whether the industrial control system requires a 4–20mA analog signal or another communication interface. Verify the wiring method, power supply and compatibility with the receiving PLC or controller.
Consider tank diameter, nozzle dimensions, internal pipes, agitators, filling points and other obstructions. The radar antenna should have a suitable measurement path toward the target material surface.
For hazardous or outdoor environments, check the actual IP rating, explosion protection certification and regional approvals required by the installation. Request supporting documents before final procurement.
Before bulk purchasing, request the product datasheet, mechanical drawing, wiring diagram and relevant measurement test information. Confirm that the selected sensor is compatible with the tank design and control system.
Correct installation is important for stable radar level measurement. The antenna position, tank geometry, reference height and material surface conditions can influence measurement performance.
Install the radar sensor at a position that provides a suitable measurement path toward the material surface. Avoid locations where tank walls, internal pipes, agitators or other structures may produce unwanted reflections within the measurement beam.
Check the nozzle height, diameter and internal geometry before selecting the antenna and process connection. The antenna should be installed according to the manufacturer's mechanical drawing and installation recommendations.
Configure the reference height and measurement range according to the tank or silo dimensions. Verify the empty distance, maximum material level and required measurement limits during commissioning.
Connect the sensor according to its wiring diagram and electrical specifications. Verify the 12–24VDC power supply and 4–20mA signal interface where applicable. Follow the manufacturer's grounding and electrical safety instructions.
Inspect the antenna surface, housing, mounting connection and cable entry periodically. Check for material buildup, mechanical damage and signs of moisture ingress according to the operating environment and maintenance schedule.
Compare the displayed measurement with a known reference level during commissioning and periodic maintenance. Investigate unexpected fluctuations by checking installation conditions, reference settings and reflected signal quality.
MANORSHI supplies radar level measurement products for industrial automation companies, tank manufacturers, chemical processing equipment suppliers, cement plant equipment manufacturers and instrumentation distributors.
Our radar level sensor range includes different measurement applications, measuring distances and installation configurations. OEM and ODM project requirements can be evaluated according to the selected model and industrial process conditions.
To help identify a suitable radar level sensor, please provide the following project information:
Measured medium: liquid, powder, granules or other solid materials.
Tank or silo height and required measuring range.
Required measurement accuracy.
Required radar frequency and antenna configuration.
Minimum and maximum process temperature.
Operating pressure and process conditions.
Chemical composition and material compatibility requirements.
Required output signal and communication interface.
Power supply voltage and wiring configuration.
Flange, threaded or other process connection requirements.
Environmental protection and certification requirements.
Sample quantity and estimated annual purchasing volume.
Customers can request available product datasheets, mechanical drawings, wiring information and samples for engineering evaluation. Custom configurations, packaging, minimum order quantity and production lead time can be discussed according to the selected model and project requirements.
Discuss Your Radar Level Measurement Project
A radar level sensor is a non-contact measurement instrument that uses microwave signals to determine the distance between the sensor and a liquid or solid material surface. It calculates the material level based on the reflected radar signal and a configured reference distance.
A radar level sensor transmits microwave signals toward the material surface and receives the reflected energy. Its electronic processing unit calculates the distance to the surface and converts the result into a level measurement.
80GHz and 26GHz radar sensors use different microwave frequency bands. The higher frequency allows compact antenna designs and can support narrower beam characteristics. Actual measurement performance depends on antenna design, signal processing, measured medium and installation conditions.
Selected MANORSHI radar level sensor models are specified with a measuring range of 0.05–120 meters. The actual usable range depends on the selected model, material properties, antenna configuration and installation conditions.
Selected MANORSHI models are published with 2mm measurement accuracy. Always confirm the exact accuracy specification and measurement conditions for the selected model before purchasing.
Yes. Selected radar level sensor models are designed for both liquid level measurement and solid material height monitoring. Applications include liquid storage tanks, cement silos, powder storage and industrial bulk material vessels.
Radar level sensors use electromagnetic microwave signals, while ultrasonic level sensors use sound waves. Radar measurement is generally less affected by air temperature variations and gas composition. Ultrasonic measurement depends on sound propagation through the air. The correct technology depends on the process environment and application requirements.
An 80GHz radar level sensor is used for non-contact level measurement in industrial tanks, process vessels and storage silos. Its high operating frequency supports compact antenna designs and can provide focused measurement coverage when the antenna is properly designed.
The listed MANORSHI radar level sensor models provide standard 4–20mA analog output. Confirm the wiring configuration and compatibility with the receiving PLC or industrial controller before installation.
Selected MANORSHI radar level sensor models are specified for 12–24VDC power supply. Check the individual product datasheet for the exact electrical requirements and wiring arrangement.
The MNSLL-H101 and MNSLL-H105 are listed for silo and bulk material level measurement. They can be evaluated for cement powder and other solid material storage applications according to the silo geometry and operating conditions.
The MNSLL-H103 is listed for corrosive liquid tank measurement. Before selecting it, confirm the chemical compatibility of the antenna, process connection, housing and sealing materials with the actual liquid composition and concentration.
The MNSLL-H102 is listed as a high-temperature radar level sensor. Confirm the actual maximum process temperature, ambient temperature and installation requirements in the latest product datasheet before selecting it.
Radar level sensors can be used in selected dusty industrial applications, including bulk material silos. However, dust concentration, material reflection characteristics, antenna design and installation conditions should be evaluated for the specific application.
No. Radar level sensors perform non-contact measurement by transmitting microwave signals toward the material surface. The sensor can be installed above the tank or vessel without direct contact between the sensing element and the measured liquid.
4–20mA is an analog current signal widely used in industrial process control. RS485 is a serial communication interface that can support digital data exchange using compatible communication protocols. Confirm the actual interface available on the selected radar sensor model.
Selected MANORSHI radar level sensor models are listed with measuring ranges up to 120 meters. The suitable model should be selected according to the actual silo height, antenna position, material properties and required measurement accuracy.
Environmental protection depends on the selected model and housing design. Customers requiring outdoor or water-exposed installation should request the actual IP rating and relevant test reports before purchasing.
Customers can contact MANORSHI to request available product datasheets, mechanical drawings and wiring information for selected radar level sensor models. These documents help engineers evaluate installation dimensions and electrical compatibility.
MANORSHI can evaluate OEM and ODM requirements according to the selected product and project specifications. Customers can provide tank drawings, process conditions, measuring range, required output and estimated purchasing quantities for assessment.
Looking for a radar level sensor manufacturer for your industrial storage tank, cement silo, chemical process vessel or liquid monitoring system?
MANORSHI supplies radar level sensors for liquid and solid material measurement, with selected 80GHz models, 4–20mA output and long-range measurement capabilities.
Send us your measured medium, tank height, required accuracy, process temperature, output signal and installation requirements. Our team can help evaluate suitable radar level sensor models and provide available technical information for your project.
