MNS-HMB-S4 Long-Range 4D Imaging mmWave Radar
The MANORSHI MNS-HMB-S4 is a 76–79 GHz 4D imaging millimeter-wave radar with a detection range of 0.2–350 m. Designed for Level 3 and higher autonomous driving applications, it provides long-range sensing, point-cloud data and target tracking.
The radar supports static-object recognition and free-space output. Its listed application platforms include passenger vehicles and logistics robots.
Features
Long-range imaging and target tracking
Point-cloud generation
Static-object recognition
Free-space output
Reliable all-weather operation
Technical Specifications
Radar Type | 4D imaging mmWave radar |
Operating Frequency | 76–79 GHz |
Antenna Configuration | 6 TX / 8 RX (6T8R) |
Detection Range | 0.2–350 m |
Detection Angle | 120° |
Angular Resolution | 1° × 1° |
Points per Frame | 4,096 |
Tracked Targets | 128 |
Static-Object Recognition | Supported |
Free-Space Output | Supported |
Communication Interfaces | 2 × CAN-FD + Ethernet |
Supply Voltage | 9–16 V |
Power Consumption | 7 W |
Dimensions | 119 × 90 × 29.5 mm |
Weight | 335 g |
Operating Temperature | −40°C to +85°C |
Ingress Protection | IP6K9K + IP67 |
Mounting | Bracket clip mounting |
Frequently Asked Questions
What is the detection range of the MNS-HMB-S4?
The specified detection range is 0.2–350 m, with a detection angle of 120°.
How many targets can the radar track?
The MNS-HMB-S4 supports tracking of 128 targets and provides 4,096 points per frame.
Which communication interfaces does the radar provide?
The radar provides two CAN-FD interfaces and Ethernet connectivity.
