6 * 2.7mm Cylinder Shaped SMD SMT Electret Condenser Microphone

  • ME60H27
  • 6*2.7mm
  • > 52dB
  • 100dB
  • -47±2dB
  • 20-16000Hz
  • 1~10V

Product Description


Parameter

SPEC

Unit


Directional

Uni-directional

dB


Sensitivity

-47±2

dB


Impedance

680

kΩ


S/N Ratio ( A weighted network)

52(Min)

dB


Maximum Input Sound Pressure Level

100(Max)

dB


THD3%


Standard Operating Voltage

1.5

Vdc


              Operating Voltage Range

1.0~10.0

Vdc


Decrease Voltage Characteristics(Vs=2.0 to 1.5V dc)

-2(Max)

dB


Current Consumption

500(Max)

μA


Standard Test Circuit

See Fig. 1


Frequency Response Characteristic

See Fig. 2




 Memo





Standard test condition



RL=2.2kΩ, Vs=2V dc,

(@f=1kHz, Pin=1Pa, 0dB=1V/Pa,L=50cm)


Appearance drawing
