110db 105dB 12v 3200Hz ac passive buzzer for Industry
Model:
MSPT30F
Dimension:
30.6 * 16.0mm
Rated Voltage:
12Vp-p
Resonant Frequency:
3200±500HZ
SPL:
≥110dB@10cm
Current:
≤5mA
Operating Voltage:
1~40Vp-p
Inquire
Add to Basket
Specification
Appearance Drawing
Specification
TYPE (UNIT)
MSPT30F
Min. Sound Output at 10cm (dB)
110
Rated Voltage (Vp-p)
12
Operating Voltage (Vp-p)
1~40
Resonant Frequency (Hz)
3200±500
Operating Temperature (C)
-30~+70
Storage Temperature (C)
-40~+85
Appearance Drawing
110dB buzzer
105dB buzzer
buzzer for Industry
