MSO-A1625H12TR
16*12mm
Open Type
65°±15° (-6dB)
25±1.0KHz
110dB (0dB=0.02mPa)
Transmitterℜceiver
| Availability: | |
|---|---|
Specification
| Construction | Open type |
| Using method | Dual use |
| Center frequency | 25KHz±1KHz |
| Sound pressure level | 110dB (0dB=0.02mPa) |
| Ringing | ≤1.2ms |
| Directivity | 65(–6dB) |
| Capacitance | 2500pF±15% |
| Operating temperature | -30 to +80℃ |
| Storage temerature | -40 to +85℃ |
| Max.input voltage | 80Vp-p |
| Metals of case | Plastic |
Appearance Drawing
