Home / BUZZER / Magnetic Transducer / Small 3V Piezo Alarm Sound Buzzer

Small 3V Piezo Alarm Sound Buzzer

Share to:

  • MSET09G
  • 9.6 * 5mm
  • 3V
  • 2700±500Hz
  • ≥85dB@10cm
  • ≤60mA
  • 2-4V

Specification


Item

Unit

Specifications

1-1

Rated VoltageSquare Wave

V

3

1-2

Operating Voltage

V

2-4

1-3

Rated CurrentMax

mA

60

1-4

Min Sound Output at 10cm

dB

85

1-5

Resonant Frequency

Hz

2700

1-6

Coil Resistance

Ω

25±4

1-7

Operating Temperature

-30~+70

1-8

Storage Temperature

-40~+85

1-9

Weight

g

1.0

1-10

Housing Material

        NORYL

1-11

Lead Pin

     Red  Copper


Appearance drawing

9
